-3%

Máy Inline KQL kaiquan Chất lượng Châu Âu, đáp ứng mọi công suất yêu cầu

Name: Máy Inline KQL kaiquan Chất lượng Châu Âu, đáp ứng mọi công suất yêu cầu
SKU: 100KQL100-32-15/2
Price: 29000000 VND
Availability: InStock

~~30.000.000₫~~ 29.000.000₫

ĐIỀU KIỆN LÀM VIỆC;

1.Tốc độ: 2960v/ph; 1480v/ph

1. Lưu lượng 1.8-2000m³/h

2. Cột áp: H ≤ 127m

3. Nhiệt Độ chất lòng: -10 C° đến 80 C°

4. Nhiệt độ môi trường làm Việc: 40C°

còn 1 hàng (có thể đặt hàng trước)

Mua ngay Gọi điện xác nhận và giao hàng tận nơi

Mã: 100KQL100-32-15/2 Danh mục: Bơm Kaiquan, Máy Bơm Kaiquan KQL ly tâm đơn tần cánh

Thông tin chi tiết

THỐNG Số KỸ THUẬT BƠM KAIQUAN – Bơm Inline KQL, Bơm đơn tầng cánh trục đứng

Hàng có sẳn: Giao hàng 5-7 ngày bằng Viettel Post

Hàng không có sẵn: đi thường về tới Việt Nam: 10-12 tuần
Đi nhanh nhất là 35-40 ngày: chi phí nhập hàng nhanh 20.000.000 vnd/ 1 lô hàng

STT

MODEL

CÔNG SUẤT (kW)

VÒNG TUA (RPM)

ĐƯỜNG KÍNH HÚT XẢ

LƯU LƯỢNG (m3/h)

CỘT ÁP
(m)

1	50KQL11-10-0.75/2	0.75	2960	DN50	8 – 11 – 13.2	11 – 10 – 9
2	50KQL12.5-12.5-1.1/2	1.1	2960	DN50	8.8 – 12.5 – 15	13.6 – 12.5 – 11.3
3	50KQL11-16-1.1/2	1.1	2960	DN50	8 – 11 – 13.2	17 – 16 – 14
4	50KQL12.5-20-1.5/2	1.5	2960	DN50	8.8 – 12.5 – 15	21.5 – 20 – 17.8
5	50KQL10-27-1.5/2	1.5	2960	DN50	7 – 10 -11	28.35 – 27 – 26.2
6	50KQL12.5-32-2.2/2	2.2	2960	DN50	8.8 – 12.5 – 13.8	33.6 – 32 – 30
7	50KQL10-36-3/2 KQL50/170-3/2-VI	3	2960	DN50	7.3 – 10.4 – 12.5	38 – 36 – 33
8	50KQL12-44-4/2 KQL50/185-4/2-VI	4	2960	DN50	8.3 – 11.7 – 14	45.8 – 44 – 42
9	50KQL12.5-50-5.5/2 KQL50/200-5.5/2-VI	5.5	2960	DN50	8.8 – 12.5 – 15	52 – 50 – 48
10	65KQL22-10-1.1/2	1.1	2960	DN65	15.6 – 22.3 – 27	11 – 10 – 8.4
11	65KQL25-12.5-1.5/2	1.5	2960	DN65	17.5 – 25 – 30	13.7 – 12.5 – 10.5
12	65KQL22-16-2.2/2	2.2	2960	DN65	15.6 – 22.3 – 27	17 – 16 – 14.4
13	65KQL25-20-2.2/2	2.2	2960	DN65	17.5 – 25 – 27.5	21 – 20 – 18.5
14	65KQL20-24-2.2/2	2.2	2960	DN65	14 – 20 – 22	25.2 – 24 – 23.2
15	65KQL23-28-3/2	3	2960	DN65	16.1 – 23 – 25.3	29.4 – 28 – 26.8
16	65KQL25-32-4/2	4	2960	DN65	17.5 – 25 – 30	34.3 – 32 – 28.5
17	65KQL22-38-5.5/2	5.5	2960	DN65	15.2 – 21.8 – 26.2	40 – 38 – 34.5
18	65KQL23-44-5.5/2 KQL65/185-7.5/2-VI	5.5	2960	DN65	16.4 – 23.4 – 25.7	46.2 – 44 – 39.6
19	65KQL25-50-7.5/2	7.5	2960	DN65	17.5 – 25 – 30	52.7 – 50 – 45.5
20	80KQL45-10-2.2/2	2.2	2960	DN80	31.3 – 44.7 – 53.6	11.5 – 10 – 8
21	80KQL50-12.5-3/2	3	2960	DN80	35 – 50 – 60	14 – 12.5 – 10.1
22	80KQL45-16-3/2	3	2960	DN80	31.5 – 45 – 49.5	17.5 – 16 – 15
23	80KQL50-20-4/2	4	2960	DN80	35 – 50 – 55	21 – 20 – 18.3
24	80KQL40-24-4/2	4	2960	DN80	28 – 40 – 44	25.2 – 24 – 21.6
25	80KQL47-28-5.5/2	5.5	2960	DN80	32.69 – 46.7 – 51.37	30 – 28 – 25.8
26	80KQL50-32-7.5/2	7.5	2960	DN80	35 – 50 – 60	35 – 32 – 28
27	80KQL35-34-5.5/2	5.5	2960	DN80	24.5 – 35 – 38.5	35.7 – 34 – 32
28	80KQL44-38-7.5/2	7.5	2960	DN80	30.5 – 43.5 – 52	40.6 – 38 – 33.4
29	80KQL47-44-11/2	11	2960	DN80	32.8 – 47 – 56.4	47 – 44 – 40
30	80KQL50-50-15/2	15	2960	DN80	35 – 50 – 60	53.5 – 50 – 46
31	80KQL43-60-15/2	15	2960	DN80	30 – 43.3 – 52	62 – 60 – 54
32	80KQL47-70-18.5/2	18.5	2960	DN80	32.5 – 46.7 – 56	73 – 70 – 63
33	80KQL50-80-22/2	22	2960	DN80	35 – 50 – 60	83 – 80 – 72
34	80KQL40-85-22/2	22	2960	DN80	28 – 40 – 48	88 – 85 – 78
35	80KQL43-101-30/2	30	2960	DN80	30 – 43.3 – 52	105 – 101 – 94
36	80KQL47-113-30/2	30	2960	DN80	32.5 – 46.7 – 56	117 – 113 – 106
37	80KQL50-125-37/2	37	2960	DN80	35 – 50 – 60	129 – 125 – 118
38	80KQL25-20-3/4	3	2960	DN80	15 – 25 – 30	21 – 20 – 18.3
39	80KQL23-28-4/4	4	2960	DN80	14 – 23 – 28	28.3 – 27.9 – 25.3
40	80KQL25-32-5.5/4	5.5	2960	DN80	15 – 25 – 30	33 – 32 – 30
41	100KQL60-16-4/2	4	2960	DN100	42 – 60 – 66	17.5 – 16 – 14.8
42	100KQL70-20-5.5/2	5.5	2960	DN100	49 – 70 – 77	22 – 20 – 18.5
43	100KQL70-26-7.5/2	7.5	2960	DN100	49 – 70 -77	27.3 – 26 – 24.3
44	100KQL75-32-11/2	11	2960	DN100	52.5 – 75 – 82.5	34.5 – 32 – 29.3
45	100KQL68-38-11/2	11	2960	DN100	47.6 – 68 – 74.8	41 – 38 – 34.2
46	100KQL72-44-15/2	15	2960	DN100	50.4 – 72- 79.2	48.5 – 44 – 41
47	100KQL75-50-18.5/2	18.5	2960	DN100	52.5 – 75 – 82.5	53 – 50 – 46
48	100KQL89-10-4/2	4	2960	DN100	62.6 – 89 – 107	12 – 10 – 8.8
49	100KQL100-12.5-5.5/2	5.5	2960	DN100	70 – 100 – 120	13.6 – 12.5 – 8
50	100KQL85-16-5.5/2	5.5	2960	DN100	59.5 – 85 – 93.5	16.8 – 16 – 14.4
51	100KQL95-20-7.5/2	7.5	2960	DN100	66.5 – 95 – 104.5	22.8 – 20 – 18.5
52	100KQL80-24-7.5/2	7.5	2960	DN100	56 – 80 – 88	25.2 – 24 – 22.4
53	100KQL94-28-11/2	11	2960	DN100	65.4 – 93.5 – 112	32 – 28 – 23
54	100KQL100-32-15/2	15	2960	DN100	70 – 100 – 120	35 – 32 – 27
