Máy bơm Inline KQL Kaiquan Chất lượng tốt đạt tiêu chuẩn Châu Âu

Name: Máy bơm Inline KQL Kaiquan Chất lượng tốt đạt tiêu chuẩn Châu Âu
SKU: 200KQL400-80-132/4
Price: 217000000 VND
Availability: InStock

~~220.000.000₫~~ 217.000.000₫

ĐIỀU KIỆN LÀM VIỆC;

1.Tốc độ: 2960v/ph; 1480v/ph

1. Lưu lượng 1.8-2000m³/h

2. Cột áp: H ≤ 127m

3. Nhiệt Độ chất lòng: –10 C° đến 80 C°

4. Nhiệt độ môi trường làm Việc: 40 C

còn 1 hàng (có thể đặt hàng trước)

Mua ngay Gọi điện xác nhận và giao hàng tận nơi

Mã: 200KQL400-80-132/4 Danh mục: Máy Bơm Kaiquan KQL ly tâm đơn tần cánh, Máy bơm nước Kaiquan

Thông tin chi tiết

TẤT CẢ THỐNG SỐ KỸ THUẬT BƠM KAIQUAN – Bơm Inline KQL, Bơm đơn tầng cánh trục đứng

Hàng có sẵn: Giao hàng 5-7 ngày bằng Viettel Post

Hàng không có sẵn: đi thường về tới Việt Nam: 10-12 tuần
Đi nhanh nhất là 35-40 ngày: chi phí nhập hàng nhanh 20.000.000 vnd/ 1 lô hàng

STT

MODEL

CÔNG SUẤT (kW)

VÒNG TUA (RPM)

ĐƯỜNG KÍNH HÚT XẢ

LƯU LƯỢNG (m3/h)

CỘT ÁP
(m)

100KQL115-34-15/2	15	2960	DN100	80.5 – 115 – 126.5	38.5 – 34 – 32
100KQL94-44-18.5/2	18.5	2960	DN100	65.4 – 93.5 – 112	47.5 – 44 – 37
100KQL100-50-22/2	22	2960	DN100	70 – 100 – 120	54 – 50 – 42
100KQL87-60-30/2	30	2960	DN100	61 – 87 – 104	65 – 60 – 50
100KQL94-70-30/2	30	2960	DN100	65.4 – 93.5 – 112	76 – 70 – 59
100KQL100-80-37/2	37	2960	DN100	70 – 100 – 120	87 – 80 – 68
100KQL82-85-37/2	37	2960	DN100	58 – 82 – 98.5	88 – 85 – 78
100KQL90-101-45/2	45	2960	DN100	63 – 90 – 108	105 – 101 – 94
100KQL95-113-55/2	55	2960	DN100	66 – 95 – 114	117 – 113 – 106
100KQL100-125-75/2	75	2960	DN100	70 – 100 -120	129 – 125 – 118
100KQL50-8-2.2/4	2.2	1480	DN100	30 – 50 -60	9.2 – 8 – 6.8
100KQL45-10-2.2/4	2.2	1480	DN100	26.8 – 44.6 – 53.5	10.7 – 9.9 – 9.4
100KQL50-12.5-3/4	3	1480	DN100	30 – 50 – 60	13.5 – 12.5 – 11.8
100KQL47-17-4/4	4	1480	DN100	28 – 46.7 – 56	18.6 – 17.4 – 16.6
100KQL50-20-5.5/4	5.5	1480	DN100	30 – 50 – 60	21.3 – 20 – 19
100KQL47-28-7.5/4	7.5	1480	DN100	28 – 46.7 – 56	29.6 – 27.9 – 26.1
100KQL50-32-11/4	11	1480	DN100	30 -50 – 60	34 – 32 – 29
125KQL143-10-7.5/2	7.5	2960	DN125	86 – 143 – 172	14 – 10 – 7
125KQL160-12.5-11/2	11	2960	DN125	96 – 160 – 192	18 – 12.5 – 8
125KQL143-16-11/2	11	2960	DN125	86 – 143 – 172	19.2 – 16 – 11.5
125KQL160-20-15/2	15	2960	DN125	96 – 160 – 192	25 – 20 – 17
125KQL138-24-15/2	15	2960	DN125	83 – 138 – 166	26 – 24 – 21
125KQL150-28-18.5/2	18.5	2960	DN125	90 – 150 – 180	31.5 – 28 – 24.5
125KQL160-32-22/2	22	2960	DN125	96 – 160 – 192	36 – 32 – 28
125KQL138-38-22/2	22	2960	DN125	83 – 138 – 166	41.3 – 37.5 – 34.5
125KQL150-44-30/2	30	2960	DN125	90 – 150 -180	48.4 – 44 – 40.5
125KQL160-50-37/2	37	2960	DN125	96 – 160 – 192	55 – 50 – 46
125KQL138-60-37/2	37	2960	DN125	83 – 138 – 166	66 – 60 – 55
125KQL150-70-45/2	45	2960	DN125	90 – 150 – 180	76 – 70 – 64
125KQL160-80-55/2	55	2960	DN125	96 – 160 – 192	87 – 80 – 73
125KQL134-88-55/2	55	2960	DN125	80.5 – 134 – 161	96 – 88 – 81
125KQL143-100-75/2	75	2960	DN125	86 – 143 – 172	108 – 100 – 94
125KQL150-110-75/2	75	2960	DN125	90 – 150 – 180	115 – 110 – 102
125KQL160-125-90/2	90	2960	DN125	96 – 160 – 192	132 – 125 – 118
125KQL100-5-2.2/4	2.2	1480	DN125	60 – 100 – 200	6.5 – 5 – 4
125KQL87-6-3/4	3	1480	DN125	52 – 87 – 104	7.5 – 6.3 – 5.1
125KQL100-8-4/4	4	1480	DN125	60 – 100 -120	9.4 – 8 – 6.7
125KQL100-12.5-5.5/4	5.5	1480	DN125	60 – 100 – 120	14 – 12.5 – 11
125KQL87-15-5.5/4	5.5	1480	DN125	52 – 87 – 104	16.4 – 15 – 14
125KQL93-17-7.5/4	7.5	1480	DN125	56 – 93 – 112	19 – 17.4 – 15.5
125KQL120-16-7.5/4	7.5	1480	DN125	84 – 120 – 132	18.5 – 16 – 14.4
125KQL100-20-11/4	11	1480	DN125	60 – 100 – 120	21.5 – 20 – 18
125KQL79-20-7.5/4	7.5	1480	DN125	47 – 79 – 95	21 – 20 – 18
125KQL91-27-11/4	11	1480	DN125	55 – 91 – 110	29 – 27 – 22
125KQL100-32-15/4	15	1480	DN125	60 – 100 – 120	35 – 32 – 27
125KQL87-38-18.5/4	18.5	1480	DN125	52.3 – 87 – 105	39 – 38 – 37
125KQL94-44-22/4	22	1480	DN125	56.4 – 94 – 113	46 – 44 – 41
125KQL100-50-30/4	30	1480	DN125	60 – 100 – 120	52 – 50 – 47
150KQL140-20-11/4	11	1480	DN150	98 – 140 – 154	21 – 20 – 18.4
150KQL160-24-15/4	15	1480	DN150	112 – 160 – 176	25.2 – 24 – 22.5
150KQL150-28-18.5/4	18.5	1480	DN150	105 – 150 – 165	29.4 – 28 – 26.5
150KQL160-32-22/4	22	1480	DN150	112 – 160 – 176	33.6 – 32 – 30
150KQL138-38-22/4	22	1480	DN150	96.6 – 138 – 151.8	39.9 – 38 – 36.2
150KQL150-44-30/4	30	1480	DN150	105 – 150 – 165	46.2 – 44 – 41.5
150KQL160-50-37/4	37	1480	DN150	112 – 160 – 176	52.5 – 50 – 47
150KQL179-10-11/4	11	1480	DN150	125 – 179 – 215	11.6 – 10 – 8
150KQL200-12.5-11/4	11	1480	DN150	140 – 200 – 240	14.1 – 12.5 – 10.6
150KQL180-16-11/4	11	1480	DN150	126 – 180 – 198	16.8 – 16 – 14.4
150KQL200-20-15/4	15	1480	DN150	140 – 200 – 220	21.8 – 20 – 18.5
150KQL240-20-18.5/4	18.5	1480	DN150	240	20
150KQL173-24-18.5/4	18.5	1480	DN150	121 – 173 – 208	25.8 – 24 – 20.7
150KQL200-28-22/4	22	1480	DN150	140 – 200 -220	31 – 28 – 25.2
150KQL200-32-30/4	30	1480	DN150	140 – 200 – 240	35 – 32 – 28
150KQL240-32-30/4	30	1480	DN150	171 – 240 – 264	35.2 – 32 – 28.8
150KQL200-38-30/4	30	1480	DN150	140 – 200 – 210	39.9 – 38 – 36
150KQL187-44-37/4	37	1480	DN150	131 – 187 – 225	46.6 – 44 – 39
150KQL200-50-45/4	45	1480	DN150	140 – 200 -240	53 – 50 – 44
150KQL173-60-55/4	55	1480	DN150	121 – 173 – 208	64 – 60 – 55.5
150KQL180-70-55/2	55	2960	DN150	126 – 180 – 216	75 – 70 – 64
150KQL187-70-75/4	75	1480	DN150	131 – 187 – 224	74 – 70 – 64
150KQL200-80-75/2	75	2960	DN150	140 – 200 – 240	86 – 80 – 72
150KQL200-80-75/4	75	1480	DN150	140 – 200 – 240	85 – 80 -75
200KQL280-10-11/4	11	1480	DN200	196 – 280 – 308	11.5 – 10 – 8.6
200KQL300-12.5-15/4	15	1480	DN200	210 – 300 – 330	15 – 12.5 – 11
200KQL280-16-18.5/4	18.5	1480	DN200	196 – 280 – 336	18 – 16 – 13
200KQL300-20-22/4	22	1480	DN200	210 – 300 – 330	21.5 – 20 – 18
200KQL245-24-22/4	22	1480	DN200	171 – 245 – 270	25.4 – 24 – 21.6
200KQL280-28-30/4	30	1480	DN200	196 – 280 – 308	30.6 – 28 – 26.2
200KQL300-32-37/4	37	1480	DN200	210 – 300 – 330	34.5 – 32 – 29.5
200KQL260-38-45/4	45	1480	DN200	182 – 260 – 312	41.4 – 38 – 29.6
200KQL270-44-45/4	45	1480	DN200	189 – 270 – 297	46.2 – 44 – 39.6
200KQL300-48-55/4	55	1480	DN200	210 – 300 – 330	50.4 – 48 – 43.2
200KQL262-60-75/4	75	1480	DN200	182 – 262 – 312	64 – 60 – 44
200KQL280-70-90/4	90	1480	DN200	196 – 280 – 336	74 – 70 – 64
200KQL300-80-110/4	110	1480	DN200	210 – 300 – 360	85 – 80 – 73
200KQL358-10-15/4	15	1480	DN200	250 – 358 – 394	13 – 10 – 7
200KQL400-12.5-18.5/4	18.5	1480	DN200	280 – 400 – 440	15.2 – 12.5 – 10.2
200KQL358-16-22/4	22	1480	DN200	250 – 358 – 430	18 – 16 – 11.2
200KQL400-20-30/4	30	1480	DN200	280 – 400 – 480	23 – 20 – 14
200KQL340-24-30/4	30	1480	DN200	238 – 340 – 374	25.2 – 24 – 21.6
200KQL360-28-37/4	37	1480	DN200	252 – 360 – 396	31.5 – 28 – 25
200KQL390-32-45/4	45	1480	DN200	273 – 390 – 429	34.5 – 32 – 28.8
200KQL440-32-55/4	55	1480	DN200	440	32
200KQL340-36-45/4	45	1480	DN200	238 – 340 – 374	39 – 36 – 32.4
200KQL370-40-55/4	55	1480	DN200	259 – 370 – 407	45.5 – 40 – 36
200KQL374-44-75/4	75	1480	DN200	262 – 374 – 449	48 – 44 – 34
200KQL400-50-75/4	75	1480	DN200	280 – 400 – 480	54.5 – 50 – 39
200KQL346-60-90/4	90	1480	DN200	242 – 346 – 415	64 – 60 – 54
200KQL374-70-110/4	110	1480	DN200	262 – 374 – 449	74 – 70 – 64
200KQL400-80-132/4	132	1480	DN200	280 – 400 – 480	85 – 80 – 73
250KQL490-17-30/4	30	1480	DN250	343 – 490 – 539	19 – 17 – 15.3
250KQL520-20-37/4	37	1480	DN250	364 – 520 – 572	22 – 20 – 18
250KQL500-25-45/4	45	1480	DN250	350 – 500 – 550	26.2 – 25 – 22.5
250KQL500-28-55/4	55	1480	DN250	364 – 500 – 600	31.5 – 28 – 25
250KQL550-32-75/4	75	1480	DN250	400 – 550 – 660	33.5 – 32 – 29
250KQL500-41-75/4	75	1480	DN250	350 – 500 – 550	44 – 41 – 36.9
250KQL500-44-90/4	90	1480	DN250	365 – 500 – 600	47 – 44 – 35
250KQL500-50-90/4	90	1480	DN250	350 – 500 – 550	52.5 – 50 – 45
250KQL600-50-110/4	110	1480	DN250	600	50
250KQL480-60-132/4	132	1480	DN250	350 – 480 – 580	64 – 60 – 52.5
250KQL515-70-160/4	160	1480	DN250	375 – 515 – 620	74 – 70 – 61.2
250KQL550-80-200/4	200	1480	DN250	400- 550 – 660	85 – 80 – 73
300KQL660-18-45/4	45	1480	DN300	460 – 660 – 790	20 – 17.5 – 14
300KQL720-20-55/4	55	1480	DN300	500 – 720 – 860	23 – 20 – 16
300KQL600-24-55/4	55	1480	DN300	420 – 600 -720	26.5 – 24 – 20.6
300KQL660-28-75/4	75	1480	DN300	460 – 660 – 790	30.5 – 28 – 24
300KQL720-32-90/4	90	1480	DN300	500 – 720 – 860	35 – 32 – 28
300KQL600-38-90/4	90	1480	DN300	420 – 600 -720	42 – 38 – 34
300KQL660-44-110/4	110	1480	DN300	460 – 660 – 790	49 – 44 – 37
300KQL720-50-132/4	132	1480	DN300	500 – 720 – 860	55 – 50 – 42
300KQL820-17-55/4	55	1480	DN300	820	17
300KQL820-24-75/4	75	1480	DN300	820	24
300KQL900-28-90/4	90	1480	DN300	900	28
300KQL900-32-110/4	110	1480	DN300	900	32
350KQL860-28-110/4	110	1480	DN350	602 – 860 – 1032	31 – 28 – 23
350KQL960-32-132/4	132	1480	DN350	672 – 960 – 1152	35 – 32 – 27.5
350KQL1000-24-110/4	110	1480	DN350	750 – 1000 – 1200	27 – 24 – 20
350KQL1100-28-132/4	132	1480	DN350	820 – 1100 – 1300	31 – 28 – 23
350KQL1200-32-160/4	160	1480	DN350	900 – 1200 – 1400	36 – 32 – 27
350KQL720-11-37/6	37	980	DN350	720	11
350KQL820-13-45/6	45	980	DN350	820	13
